| Specification | Unit | VMC1680LB | VMC1886LB | VMC2210LB |
| Table(lenghtXwidth) | mm | 1600X800 | 1800X860 | 2000X1000 |
| T-slot | mm | 18X7X100 | 22X5X150 | 22X7X150 |
| Max loading weight | kg | 2000x1500x1800 | 2000 | 3000 |
| X/Y/Z travel | mm | 1600/800/700 | 1800/860/700 | 2200/1000/900 |
| From table to spindle nose | mm | 175-875 | 190-890 | 65-965 |
| Spindle center to z axis guide way | mm | 930 | 930 | 1060 |
| Spindle nose to flexible guard shell | mm | 860 | 860 | 1000 |
| Spindle speed | rpm | 6000 | 6000 | 6000 |
| Rapid speed X/Y/Z | m/min | 20/20/15 | 20/20/15 | 20/20/15 |
| Cutting feed speed | m/min | 1-15 | 1-15 | 1-10 |
| Tool magazine | piece | BT50/24T | BT50/24T | BT50/24T |
| Tool-to-tool random | Chain Type(Disc) |
Chain Type(Disc) |
Chain Type(Disc) |
|
| Max.tool holder | mm | 110 | 110 | 110 |
| No adjacent tool | mm | 200 | 200 | 200 |
| Tool max length | mm | 300 | 300 | 300 |
| Tool max weight | kg | 15 | 15 | 15 |
| Feed motor | kw | 4/4/4 | 4/4/7 | 7/7/7 |
| Main motor | kw | 15/18.5 | 15/18.5 | 15/18.5 |
| Cooling device | 750 | 750 | 750 | |
| Cooling device motor | kw | 1.27 | 1.27 | 1.27 |
| Cooling device capacity | L | 350 | 350 | 450 |
| Air source | kg/cm2 | 6 | 6 | 6 |
| Power | KVA | 35 | 40 | 45 |
| Re-positional accuracy | mm | ISO10791-4 R:0.007 | ISO10791-4 R:0.007 | R:0.010 |
| Positional accuracy | mm | ISO10791-4 A:0.008 | ISO10791-4 A:0.008 | A:0.014 |
| Weiht | kg | 12000 | 14000 | 16500 |
