RDP86016B / RDP86016F
Order No.:
Stock: 20
Delivery Time: 30
Without Tax: $
Machine video: 230-260
QUICK OVERVIEW
Contact us
Order No.:
Stock: 20
Delivery Time: 30
Without Tax: $
Machine video: 230-260
QUICK OVERVIEW
Contact us
| Model | RDP86016B | RDP86016F |
| Drill Capacity | 16mm | 16mm |
| Chuck Capacity | 16mm | 16mm |
| Swing | 34″(860mm) | 34″(860mm) |
| Spindle Taper | MT2 | MT2 |
| Speed Range(50HZ) | 5(500-2500) | 5(500-2500) |
| Speed Range(60HZ) | 5(620-3100) | 5(620-3100) |
| Spindle Travel | 80mm | 80mm |
| Head Tilt | 45°R-90°L | 45°R-90°L |
| Table Size | 285*220mm | Φ300mm |
| Table Tilt | 45° | 45° |
| Column Diameter | 59.5mm | 73mm |
| Rack & Pinion | YES | YES |
| Base Size | 350*215mm | 456*280mm |
| Overall Height | 810mm | 1630mm |
| Motor | 400W | 400W |
| N.W./G.W | 40/44kgs | 58/62kgs |
| Packing Size | 910*360*320mm | 1400*490*250mm |
| Units Per 20′Container | 266pcs | 160pcs |
